RoHS
RoHS RoHS compliant
Package /
Category Cables, Wires / Multiple Conductor Cables
Description Cable;2Cond;16AWG;19x0.0117;TC;PVC ins;White overall;CMR
PDF
/
Inventory: 1645
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Insulation Thickness 812.8μm
Jacket (Insulation) Thickness 0.0320 0.813mm
Length 500.0' 152.4m

Technical

Conductor Insulation Poly-Vinyl Chloride (PVC)
Insulation Diameter 6.9596 mm
Jacket (Insulation) Diameter 0.274 (6.96mm)
Usage Audio-Video, Home
Conductor Strand 19/0.0117
Jacket Color White
Wire/Cable Gauge 16 AWG
Cable Type Speaker
Voltage 300V
Wire Gauge 16 AWG
Approval Agency UL
Number of Conductors 2
Color White
Min Operating Temperature -20°C
Max Operating Temperature 75°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Packaging Spool
Operating Temperature -20°C~75°C

Physical

Jacket (Insulation) Material Poly-Vinyl Chloride (PVC)
Conductor Material Copper, Tinned
Insulation Material PVC
Mount Cable
