C0924A.38.10
RoHS
RoHS compliant
RoHS compliantPackage /
Category Cables, Wires / Multiple Conductor Cables
Description
MULTI-PAIR 4COND 24AWG SHLD 500'
PDF
/
Inventory: 6439
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings ASTM B-33
RoHS Status RoHS Compliant
Dimensions
Insulation Thickness 1.2192mm
Jacket (Insulation) Thickness 0.0480 1.219mm
Length 500.0' 152.4m
Technical
Shield Coverage 100%, 70%
Shield Type Foil, Braid
Conductor Insulation Polypropylene (PP)
Insulation Diameter 9.9568 mm
Jacket (Insulation) Diameter 0.392 (9.96mm)
Usage Computer
Conductor Strand 7/32
Jacket Color Gray
Wire/Cable Gauge 24 AWG
Wire/Cable Type Multi-Pair
Cable Type Multi-Pair
Voltage 300V
Wire Gauge 24 AWG
Number of Conductors 4 (2 Pair Twisted)
Color Grey
Min Operating Temperature -20°C
Max Operating Temperature 75°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Drain Wire
Operating Temperature -20°C~75°C
Physical
Shield Material Flexfoil?, Copper, Tinned
Jacket (Insulation) Material Poly-Vinyl Chloride (PVC)
Conductor Material Copper, Annealed Tinned
Insulation Material PVC
Mount Cable
