RoHS
RoHS RoHS compliant
Package /
Category Cables, Wires / Multiple Conductor Cables
Description MULTI-PAIR 8COND 24AWG GRY 3281'
PDF
/
Inventory: 1816
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

Insulation Diameter 6.223 mm
Jacket (Insulation) Diameter 0.245 (6.22mm)
Usage Computer
Conductor Strand 7/32
Jacket Color Gray
Wire/Cable Gauge 24 AWG
Wire/Cable Type Multi-Pair
Cable Type Multi-Pair
Voltage 300V
Wire Gauge 24 AWG
Number of Conductors 8 (4 Pair Twisted)
Color Grey
Min Operating Temperature -20°C
Max Operating Temperature 80°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Drain Wire
Packaging Spool
Operating Temperature -20°C~80°C
Shield Coverage 100%
Shield Type Foil
Conductor Insulation Poly-Vinyl Chloride (PVC)

Physical

Shield Material Flexfoil?
Jacket (Insulation) Material Poly-Vinyl Chloride (PVC)
Conductor Material Copper, Annealed Tinned
Insulation Material PVC

Compliance

Ratings ASTM B-33
RoHS Status RoHS Compliant

Dimensions

Insulation Thickness 812.8μm
Jacket (Insulation) Thickness 0.0320 0.813mm
Length 3281' 1000.0m
