89063.35.01
RoHS
RoHS compliant
RoHS compliantPackage 100
Category Cables, Wires / Multiple Conductor Cables
Description
CABLE 3COND 16AWG BLACK 250
PDF
/
Buying Options
Total Price: USD $89.42
Unit Price: USD $89.4168
≥1 USD $89.4168
≥10 USD $73.1632
≥100 USD $56.90432
Inventory: 87
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Cable
Package / Case 100
Insulation Material TPE
Conductor Material Copper, Bare
Jacket (Insulation) Material Thermoplastic Elastomer (TPE)
Technical
Operating Temperature -50°C~105°C
Packaging Spool
Series Ultra Flex?
Feature Oil Resistant
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 105°C
Min Operating Temperature -50°C
Color Black
Number of Conductors 3
Wire Gauge 16 AWG
Voltage 600V
Cable Type Multi-Conductor
Wire/Cable Type Multi-Conductor
Wire/Cable Gauge 16 AWG
Jacket Color Black
Conductor Strand 26/30
Usage Cord and Cordset
Jacket (Insulation) Diameter 0.400 (10.16mm)
Insulation Diameter 10.16 mm
Conductor Insulation Thermoplastic Elastomer (TPE)
Dimensions
Length 250.0' 76.2m
Jacket (Insulation) Thickness 0.0300 0.762mm
Insulation Thickness 762μm
Compliance
RoHS Status RoHS Compliant
