89013.35.05
RoHS
RoHS compliant
RoHS compliantPackage 100
Category Cables, Wires / Multiple Conductor Cables
Description
CABLE 3COND 16AWG YELLOW 250
PDF
/
Buying Options
Total Price: USD $158.45
Unit Price: USD $158.4528
≥1 USD $158.4528
≥10 USD $129.64512
≥100 USD $100.8348
Inventory: 91
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Insulation Thickness 762μm
Jacket (Insulation) Thickness 0.0300 0.762mm
Length 250.0' 76.2m
Technical
Conductor Insulation Thermoplastic Elastomer (TPE)
Insulation Diameter 8.5852 mm
Jacket (Insulation) Diameter 0.338 (8.59mm)
Usage Cord and Cordset
Conductor Strand 26/30
Jacket Color Yellow
Wire/Cable Gauge 16 AWG
Wire/Cable Type Multi-Conductor
Cable Type Multi-Conductor
Voltage 300V
Wire Gauge 16 AWG
Number of Conductors 3
Color Yellow
Min Operating Temperature -50°C
Max Operating Temperature 105°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Oil Resistant
Series Ultra Flex?
Packaging Spool
Operating Temperature -50°C~105°C
Physical
Jacket (Insulation) Material Thermoplastic Elastomer (TPE)
Conductor Material Copper, Bare
Insulation Material TPE
Package / Case 100
Mount Cable
Supply Chain
Factory Lead Time 6 Weeks
