86963.35.05
RoHS
RoHS compliant
RoHS compliantPackage /
Category Cables, Wires / Multiple Conductor Cables
Description
CABLE 3COND 16AWG YELLOW 250'
PDF
/
Buying Options
Total Price: USD $198.7
Unit Price: USD $198.704
≥1 USD $198.704
Inventory: 52
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Cable
Insulation Material PVC
Conductor Material Copper, Bare
Jacket (Insulation) Material Poly-Vinyl Chloride (PVC)
Technical
Operating Temperature -40°C~90°C
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 90°C
Min Operating Temperature -40°C
Color Yellow
Number of Conductors 3
Wire Gauge 16 AWG
Voltage 600V
Cable Type Multi-Conductor
Wire/Cable Type Multi-Conductor
Wire/Cable Gauge 16 AWG
Jacket Color Yellow
Conductor Strand 26/30
Jacket (Insulation) Diameter 0.395 (10.03mm)
Insulation Diameter 10.033 mm
Dimensions
Length 250.0' 76.2m
Jacket (Insulation) Thickness 0.0300 0.762mm
Insulation Thickness 762μm
Compliance
RoHS Status RoHS Compliant
