6133492.2.5R
RoHS
RoHS compliant
RoHS compliantPackage /
Category Cables, Wires / Multiple Conductor Cables
Description
CABLE CAT5E 8COND 23AWG 2500'
PDF
/
Inventory: 5023
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Cable
Insulation Material PVC
Conductor Material Copper, Bare
Jacket (Insulation) Material Poly-Vinyl Chloride (PVC)
Technical
Operating Temperature -20°C~75°C
Series GenSPEED? 5500
Feature Rip Cord
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 75°C
Min Operating Temperature -20°C
Color White
Number of Conductors 8 (4 Pair Twisted)
Wire Gauge 23 AWG
Cable Type Multi-Pair, Cat5e
Wire/Cable Type Multi-Pair
Wire/Cable Gauge 23 AWG
Jacket Color White
Conductor Strand Solid
Jacket (Insulation) Diameter 0.220 (5.59mm)
Insulation Diameter 5.588 mm
Conductor Insulation Polyolefin (PO)
Dimensions
Length 2500' 762.0m
Compliance
RoHS Status RoHS Compliant
