16093.35.01
RoHS
RoHS compliant
RoHS compliantPackage /
Category Cables, Wires / Multiple Conductor Cables
Description
CABLE 3COND 2AWG BLACK 250'
PDF
/
Inventory: 7211
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Insulation Thickness 1.524mm
Jacket (Insulation) Thickness 0.0600 1.524mm
Length 250.0' 76.2m
Technical
Conductor Insulation Ethylene Propylene Terpolymer Rubber (EPDM)
Insulation Diameter 33.782 mm
Jacket (Insulation) Diameter 1.330 (33.78mm)
Conductor Strand 133/23
Jacket Color Black
Wire/Cable Gauge 2 AWG
Wire/Cable Type Multi-Conductor
Cable Type Multi-Conductor
Voltage 600V
Wire Gauge 2 AWG
Number of Conductors 3
Color Black
Min Operating Temperature -40°C
Max Operating Temperature 90°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Operating Temperature -40°C~90°C
Physical
Jacket (Insulation) Material Carolprene
Conductor Material Copper, Bare
Mount Cable
