01825.33.01
RoHS
/
Package 100
Category Cables, Wires / Multiple Conductor Cables
Description
CABLE 3COND 6AWG BLACK 100'
PDF
/
Inventory: 4531
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Cable
Package / Case 100
Conductor Material Copper, Bare
Jacket (Insulation) Material Carolprene
Technical
Operating Temperature -40°C~90°C
Packaging Spool
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 90°C
Min Operating Temperature -40°C
Color Black
Number of Conductors 3
Wire Gauge 6 AWG
Voltage 600V
Cable Type Multi-Conductor
Wire/Cable Type Multi-Conductor
Wire/Cable Gauge 6 AWG
Jacket Color Black
Conductor Strand 101/26
Usage Cord and Cordset
Jacket (Insulation) Diameter 0.790 (20.07mm)
Insulation Diameter 20.066 mm
Conductor Insulation Ethylene Propylene Terpolymer Rubber (EPDM)
Dimensions
Length 100.0' 30.5m
Jacket (Insulation) Thickness 0.0500 1.270mm
Insulation Thickness 1.27mm
Compliance
RoHS Status RoHS Compliant
