8880MN 006100
RoHS
/
Package /
Category Cables, Wires / Multiple Conductor Cables
Description
CBL 12COND 20AWG SHLD
PDF
/
Inventory: 3006
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Conductor Material Copper, Tinned
Jacket (Insulation) Material Poly-Vinyl Chloride (PVC)
Shield Material Aluminum
Technical
Operating Temperature -20°C~80°C
Packaging Spool
Series SpaceMaker?
Feature Drain Wire
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Conductors 12
Wire Gauge 20 AWG
Voltage 300V
Cable Type Multi-Conductor
Jacket Color Blue
Conductor Strand 26/34
Usage Audio, Control, Instrumentation
Jacket (Insulation) Diameter 0.273 (6.93mm)
Conductor Insulation Polypropylene (PP)
Shield Type Foil
Shield Coverage 100%
Dimensions
Length 100.0' 30.5m
Jacket (Insulation) Thickness 0.0160 0.406mm
Compliance
Ratings UL Style 2937
