8875MN 006100
RoHS
/
Package /
Category Cables, Wires / Multiple Conductor Cables
Description
CBL 2PR 18AWG SHLD
PDF
/
Inventory: 6784
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings UL Style 2937
Dimensions
Jacket (Insulation) Thickness 0.0160 0.406mm
Length 100.0' 30.5m
Technical
Shield Coverage 100%
Shield Type Foil
Conductor Insulation Polypropylene (PP)
Jacket (Insulation) Diameter 0.290 (7.37mm)
Usage Audio, Control, Instrumentation
Conductor Strand 41/34
Jacket Color Blue
Cable Type Multi-Pair
Voltage 300V
Wire Gauge 18 AWG
Number of Conductors 4 (2 Pair Twisted)
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Drain Wire
Series SpaceMaker?
Packaging Spool
Operating Temperature -20°C~80°C
Physical
Shield Material Aluminum
Jacket (Insulation) Material Poly-Vinyl Chloride (PVC)
Conductor Material Copper, Tinned
Supply Chain
Factory Lead Time 3 Weeks
