88723 002500
RoHS
RoHS compliant
RoHS compliantPackage /
Category Cables, Wires / Multiple Conductor Cables
Description
MULTI-PAIR 4COND 22AWG RED 500'
PDF
/
Buying Options
Total Price: USD $7.02
Unit Price: USD $7.0225
≥1 USD $7.0225
≥10 USD $6.625
≥100 USD $6.25
≥500 USD $5.89623
≥1000 USD $5.56248
≥3000 USD $5.24762
Inventory: 8107
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 2 Weeks
Physical
Conductor Material Copper, Tinned
Jacket (Insulation) Material Fluorinated Ethylene-Propylene (FEP)
Shield Material Aluminum
Technical
Operating Temperature -70°C~200°C
Packaging Spool
Published 2011
Feature Drain Wire
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Conductors 4 (2 Pair Twisted)
Wire Gauge 22 AWG
Connector Support Type WIRE AND CABLE
Cable Type Multi-Pair
Jacket Color Red
Conductor Strand 7/30
Jacket (Insulation) Diameter 0.148 (3.76mm)
Conductor Insulation Fluorinated Ethylene-Propylene (FEP)
Shield Type Foil
Shield Coverage 100%
Dimensions
Length 500.0' 152.4m
Jacket (Insulation) Thickness 0.0140 0.356mm
Compliance
RoHS Status ROHS3 Compliant
Ratings UL Style CMP
