88109 0081000
RoHS
RoHS compliant
RoHS compliantPackage /
Category Cables, Wires / Multiple Conductor Cables
Description
CBL 9PR 24AWG SHLD
PDF
/
Inventory: 9148
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings UL Style CMP
RoHS Status RoHS Compliant
Dimensions
Jacket (Insulation) Thickness 0.0140 0.356mm
Length 1000.0' 304.8m
Technical
Wire and Cable Name COMMUNICATION CABLE
Shield Coverage 100%
Shield Type Foil
Rated Current 1.1A
Conductor Insulation Foam Fluorinated Ethylene-Propylene (FFEP)
Jacket (Insulation) Diameter 0.352 (8.94mm)
Usage Computer
Conductor Strand 7/32
Jacket Color Gray
Cable Type Multi-Pair
Connector Support Type WIRE AND CABLE
Voltage 300V
Wire Gauge 24 AWG
Approval Agency CEC; CUL; NEC; UL
Number of Conductors 18 (9 Pair Twisted)
Reach Compliance Code compliant
Construction STRANDED
Shielding YES
Resistance 0.079Ohm
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Drain Wire
Published 2016
Packaging Spool
Operating Temperature -20°C~150°C
Physical
Shield Material Aluminum
Jacket (Insulation) Material Polyvinylidene Fluoride (PVDF), Plenum
Conductor Material Copper, Tinned
Supply Chain
Factory Lead Time 6 Weeks
