6502FE 007U1000
RoHS
/
Package /
Category Cables, Wires / Multiple Conductor Cables
Description
CBL 4COND 22AWG FLRST SHLD
PDF
/
Buying Options
Total Price: USD $0.22
Unit Price: USD $0.219254
≥1 USD $0.219254
Inventory: 1737
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Conductor Material Copper, Bare
Jacket (Insulation) Material Low Smoke Poly-Vinyl Chloride (LSPVC), Plenum
Shield Material Aluminum
Technical
Operating Temperature 0°C~75°C
Packaging Spool
Feature Drain Wire, Rip Cord
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Reach Compliance Code compliant
Number of Conductors 4
Wire Gauge 22 AWG
Voltage 300V
Connector Support Type WIRE AND CABLE
Cable Type Multi-Conductor
Jacket Color Violet
Conductor Strand 7/30
Usage Alarm, Security, Sound
Jacket (Insulation) Diameter 0.147 (3.73mm)
Conductor Insulation Low Smoke Poly-Vinyl Chloride (LSPVC)
Shield Type Foil
Shield Coverage 100%
Dimensions
Length 1000.0' 304.8m
Jacket (Insulation) Thickness 0.0150 0.381mm
Compliance
Ratings UL Style CMP
