5441FE 0081000
RoHS
RoHS compliant
RoHS compliantPackage /
Category Cables, Wires / Multiple Conductor Cables
Description
CBL 2PR 20AWG FRPVC SHLD
PDF
/
Buying Options
Total Price: USD $0.31
Unit Price: USD $0.311157
≥1 USD $0.311157
Inventory: 1436
Minimum: 1
-
+
Technical Details
Compliance
Ratings UL Style CMR
RoHS Status RoHS Compliant
Dimensions
Jacket (Insulation) Thickness 0.0170 0.432mm
Length 1000.0' 304.8m
Technical
Shield Coverage 100%
Shield Type Foil
Conductor Insulation Polypropylene (PP)
Jacket (Insulation) Diameter 0.218 (5.54mm)
Usage Alarm, Security, Sound
Conductor Strand 7/28
Jacket Color Gray
Cable Type Multi-Pair
Connector Support Type WIRE AND CABLE
Voltage 300V
Wire Gauge 20 AWG
Number of Conductors 4 (2 Pair)
Reach Compliance Code compliant
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Published 2012
Packaging Spool
Operating Temperature -20°C~75°C
Physical
Shield Material Aluminum
Jacket (Insulation) Material Poly-Vinyl Chloride (PVC), Riser
Conductor Material Copper, Bare
Supply Chain
Factory Lead Time 3 Weeks
