5200FE 008U500
RoHS
RoHS compliant
RoHS compliantPackage /
Category Cables, Wires / Multiple Conductor Cables
Description
CBL 2COND 16AWG FRPVC SHLD
PDF
/
Buying Options
Total Price: USD $0.47
Unit Price: USD $0.472644
≥1 USD $0.472644
Inventory: 9620
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Conductor Material Copper, Tinned
Jacket (Insulation) Material Poly-Vinyl Chloride (PVC), Riser
Shield Material Aluminum
Technical
Operating Temperature -20°C~75°C
Packaging Spool
Published 2012
Feature Drain Wire, Rip Cord
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Reach Compliance Code compliant
Number of Conductors 2
Wire Gauge 16 AWG
Voltage 300V
Connector Support Type WIRE AND CABLE
Cable Type Multi-Conductor
Jacket Color Gray
Conductor Strand 19/29
Usage Security, Sound
Jacket (Insulation) Diameter 0.188 (4.78mm)
Conductor Insulation Polypropylene (PP)
Shield Type Foil
Shield Coverage 100%
Dimensions
Length 500.0' 152.4m
Jacket (Insulation) Thickness 0.0170 0.432mm
Compliance
RoHS Status RoHS Compliant
Ratings UL Style CMR
