2152PE 0021000
RoHS
/
Package /
Category Cables, Wires / Multiple Conductor Cables
Description
CBL 2PR 20AWG SHLD
PDF
/
Inventory: 3982
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Conductor Material Copper, Bare
Jacket (Insulation) Material Poly-Vinyl Chloride (PVC), Plenum
Shield Material Aluminum
Technical
Operating Temperature 0°C~75°C
Packaging Spool
Feature Drain Wire, Rip Cord
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Conductors 4 (2 Pair)
Wire Gauge 20 AWG
Voltage 300V
Cable Type Multi-Pair
Jacket Color Red
Conductor Strand Solid
Usage Commercial Audio
Jacket (Insulation) Diameter 0.221 (5.61mm)
Conductor Insulation Poly-Vinyl Chloride (PVC)
Shield Type Foil
Shield Coverage 100%
Dimensions
Length 1000.0' 304.8m
Jacket (Insulation) Thickness 0.0150 0.381mm
Compliance
Ratings UL Style CMP
