M42898 SL005
RoHS
RoHS compliant
RoHS compliantPackage /
Category Cables, Wires / Multiple Conductor Cables
Description
MULTI-PAIR 24COND 24AWG 100'
PDF
/
Inventory: 7139
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Jacket (Insulation) Thickness 0.0170 0.432mm
Length 100.0' 30.5m
Technical
Shield Coverage 100%
Shield Type Foil
Conductor Insulation Fluorinated Ethylene-Propylene (FEP)
Jacket (Insulation) Diameter 0.502 (12.75mm)
Conductor Strand 7/32
Jacket Color Slate
Cable Type Multi-Pair
Voltage 300V
Wire Gauge 24 AWG
Number of Conductors 24 (12 Pair Twisted)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Drain Wire
Published 2009
Packaging Spool
Operating Temperature -20°C~150°C
Physical
Shield Material Aluminum
Jacket (Insulation) Material Polyvinylidene Fluoride (PVDF), Plenum
Conductor Material Copper, Bare
