85225CY BK001
RoHS
RoHS compliant
RoHS compliantPackage /
Category Cables, Wires / Multiple Conductor Cables
Description
XG FLEX 22AWG 5C SHIELDED
PDF
/
Inventory: 3310
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings UL Style 2587
RoHS Status RoHS Compliant
Dimensions
Jacket (Insulation) Thickness 0.0400 1.016mm
Length 1000.0' 304.8m
Technical
Shield Coverage 85%
Shield Type Braid
Conductor Insulation Poly-Vinyl Chloride (PVC)
Jacket (Insulation) Diameter 0.383 (9.73mm)
Conductor Strand 41/38
Jacket Color Black
Cable Type Multi-Conductor
Voltage 600V
Wire Gauge 22 AWG
Number of Conductors 5
Reach Compliance Code compliant
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Oil Resistant
Series Xtra-Guard? Flex
Packaging Spool
Physical
Shield Material Copper, Tinned
Jacket (Insulation) Material Poly-Vinyl Chloride (PVC)
Conductor Material Copper, Bare
Supply Chain
Factory Lead Time 5 Weeks
