5640B2201 NC001
RoHS
RoHS compliant
RoHS compliantPackage /
Category Cables, Wires / Multiple Conductor Cables
Description
CABLE 1TRIAD 22AWG SHLD 1000'
PDF
/
Buying Options
Total Price: USD $560.87
Unit Price: USD $560.868
≥1 USD $560.868
≥10 USD $555.7552
Inventory: 40
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Jacket (Insulation) Thickness 0.0380 0.965mm
Length 1000.0' 304.8m
Technical
Shield Coverage 100%
Shield Type Foil
Conductor Insulation Poly-Vinyl Chloride (PVC)
Jacket (Insulation) Diameter 0.201 (5.11mm)
Conductor Strand 7/28
Cable Type Multi-Conductor
Voltage 300V
Wire Gauge 22 AWG
Number of Conductors 3 (1 Triad Twisted)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Drain Wire
Published 2005
Packaging Spool
Operating Temperature -20°C~105°C
Physical
Shield Material Aluminum
Jacket (Insulation) Material Poly-Vinyl Chloride (PVC)
Conductor Material Copper, Bare
Supply Chain
Factory Lead Time 5 Weeks
