45464 BK199
RoHS
/
Package /
Category Cables, Wires / Multiple Conductor Cables
Description
45464 BLACK 1000 = 1000 FT
PDF
/
Buying Options
Total Price: USD $7.92
Unit Price: USD $7.92
≥1 USD $7.92
≥10 USD $7.29813
≥100 USD $7.04176
≥500 USD $6.894175
≥1000 USD $6.71088
≥3000 USD $6.30784
Inventory: 1955
Minimum: 1
-
+
Technical Details
Physical
Conductor Material Copper, Tinned
Jacket (Insulation) Material Thermoplastic Elastomer (TPE)
Shield Material Aluminum
Technical
Operating Temperature -50°C~125°C
Packaging Spool
Series Xtra-Guard? 4
Feature Biological Compatibility, Drain Wire, Rip Cord
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Conductors 4
Wire Gauge 20 AWG
Voltage 300V
Cable Type Multi-Conductor
Jacket Color Black
Conductor Strand 7/28
Jacket (Insulation) Diameter 0.268 (6.81mm)
Conductor Insulation Thermoplastic Elastomer (TPE)
Shield Type Foil
Shield Coverage 100%
Dimensions
Length 1000.0' 304.8m
Jacket (Insulation) Thickness 0.0450 1.143mm
Compliance
RoHS Status Non-RoHS Compliant
Ratings ISO 10993
