35450/9 BK199
RoHS
RoHS compliant
RoHS compliantPackage /
Category Cables, Wires / Multiple Conductor Cables
Description
35450/9 BLACK 1000 = 1000 FT
PDF
/
Inventory: 7819
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Jacket (Insulation) Thickness 0.0630 1.600mm
Length 1000.0' 304.8m
Technical
Shield Coverage 100%
Shield Type Foil
Conductor Insulation Poly-Vinyl Chloride (PVC)
Jacket (Insulation) Diameter 0.581 (14.76mm)
Conductor Strand 41/30
Jacket Color Black
Cable Type Multi-Conductor
Connector Support Type WIRE AND CABLE
Voltage 600V
Wire Gauge 14 AWG
Number of Conductors 9
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Drain Wire, Rip Cord
Series Xtra-Guard? 3
Packaging Spool
Operating Temperature -30°C~80°C
Physical
Shield Material Aluminum
Jacket (Insulation) Material Polyethylene (PE)
Conductor Material Copper, Tinned
