SPMD150STP
RoHS
RoHS compliant
RoHS compliantPackage /
Category Motors, Solenoids, Driver Boards/Modules / Motor Driver Boards, Modules
Description
STEPPER DRIVER 1.5A 10-42V LOAD
PDF
/
Buying Options
Total Price: USD $421.77
Unit Price: USD $421.76675
≥1 USD $421.76675
Inventory: 302
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 50.8mm
Length 50.8mm
Technical
Number of Motors 1
Control / Drive Type Stepper, Bipolar
Motor Type Stepper
Voltage - Load 10V~42V
Output Current-Max 2.5A
Nominal Supply Current 1.5A
Interface Step / Direction
Power Supplies 524V
Supply Voltage-Max (Vsup) 42V
Qualification Status Not Qualified
Pin Count 19
Base Part Number SPMD150
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code unknown
Terminal Pitch 2.54mm
Supply Voltage 24V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position DUAL
Voltage - Supply 3V~5.25VDC
Subcategory Motion Control Electronics
Type Module
ECCN Code EAR99
Termination PC Pin
Number of Terminations 19
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Series EASY POWER?
Operating Temperature -40°C~85°C
Physical
Number of Pins 19
Surface Mount NO
Mounting Type Through Hole
