MSA240KC image
Favorite
MSA240KC image
Favorite
RoHS
/
Package /
Category Motors, Solenoids, Driver Boards/Modules / Motor Driver Boards, Modules
Description BRUSHED DRIVER 20A 3-100V LOAD
PDF
/
Buying Options
Total Price: USD $212.47
Unit Price: USD $212.46777
≥1 USD $212.46777
≥10 USD $200.44129
≥100 USD $189.09556
≥500 USD $178.39204
≥1000 USD $168.29438
Inventory: 1578
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status Non-RoHS Compliant

Dimensions

Width 66.802mm
Length 93.726mm

Technical

Wattage - Load 250W
Number of Motors 1
Control / Drive Type Brushed
Motor Type Brushed DC
Voltage - Load 3V~100V
Current - Output 20A
Qualification Status Not Qualified
JESD-30 Code R-XDMA-T58
Pin Count 58
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 15V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form THROUGH-HOLE
Terminal Position DUAL
Voltage - Supply 14V~16VDC
Terminal Finish TIN OVER NICKEL
Type Board
Termination PC Pin
Number of Terminations 58
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
JESD-609 Code e3
Series Apex Precision Power?
Published 2012
Operating Temperature -40°C~85°C

Physical

Surface Mount NO
Mounting Type Chassis Mount

Supply Chain

Factory Lead Time 5 Weeks
