TM1000Q

E-Switch
RoHS
RoHS RoHS compliant
Package 3-SIP Module
Category Sensors, Transducers / Motion Sensors - Tilt Switches
Description TILT SWITCH
PDF
/
Buying Options
Total Price: USD $1.35
Unit Price: USD $1.3464
≥1 USD $1.3464
≥10 USD $1.29536
≥100 USD $1.217568
≥500 USD $1.051864
Inventory: 1113
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC

Technical

Operating Angle ±45°
Switching Voltage 24V
Max Voltage Rating (DC) 24V
Current - Output 20mA
Electrical Life 1e+06 cycles
Max Voltage Rating (AC) 24V
Contact Resistance 5Ohm
Output Type SPST
Orientation Right Angle
ECCN Code EAR99
Termination PC Pins
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2004
Packaging Cut Tape (CT)
Operating Temperature -25°C~70°C

Physical

Package / Case 3-SIP Module
Mounting Type Through Hole, Right Angle
Mount Through Hole

Supply Chain

Factory Lead Time 10 Weeks
