LY503ALH image
Favorite
LY503ALH image
Favorite
RoHS
RoHS RoHS compliant
Package 16-LFLGA
Category Sensors, Transducers / Motion Sensors - Gyroscopes
Description GYROSCOPE SINGLE AXIS 16-LGA
PDF
/
Inventory: 1769
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Package / Case 16-LFLGA
Surface Mount YES
Number of Pins 16

Technical

Operating Temperature -40°C~85°C TA
Packaging Tray
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 16
Type Analog
HTS Code 8542.39.00.01
Voltage - Supply 2.7V~3.6V
Terminal Position BOTTOM
Terminal Form BUTT
Number of Functions 1
Supply Voltage 3V
Terminal Pitch 0.8mm
Base Part Number LY503
Pin Count 16
Output Type Analog Voltage
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 2.7V
Operating Supply Current 6.8mA
Nominal Supply Current 5mA
Bandwidth 140Hz
Axis X (Pitch)
Range °/s ±30
Sensitivity (mV/°/s) 33.3

Dimensions

Height Seated (Max) 1.6mm
Length 5mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
