LY3200ALH
RoHS
RoHS compliant
RoHS compliantPackage 10-TLGA
Category Sensors, Transducers / Motion Sensors - Gyroscopes
Description
STMICROELECTRONICS LY3200ALH MEMS Gyroscope, Analogue, Yaw,2000/s, 2.7 V, 3.6 V, LGA
PDF
/
Buying Options
Total Price: USD $24.16
Unit Price: USD $24.16325
≥1 USD $24.16325
≥10 USD $19.8265
≥100 USD $19.2071
≥500 USD $18.5877
≥1000 USD $17.96735
Inventory: 2914
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Length 5mm
Height Seated (Max) 1.1mm
Technical
Sensitivity (mV/°/s) 0.67
Range °/s ±2000
Axis X (Pitch)
Linearity 1 %
Bandwidth 140Hz
Nominal Supply Current 4.2mA
Operating Supply Current 4.2mA
Supply Voltage-Min (Vsup) 2.7V
Power Supplies 3V
Supply Voltage-Max (Vsup) 3.6V
Output Type Analog Voltage
Pin Count 10
Base Part Number LY3200
Terminal Pitch 1.415mm
Supply Voltage 3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form BUTT
Terminal Position BOTTOM
Voltage - Supply 2.7V~3.6V
Technology CMOS
HTS Code 8542.39.00.01
Terminal Finish Nickel/Gold (Ni/Au) - electrolytic
Type Analog
Number of Terminations 10
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Packaging Tray
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 10
Package / Case 10-TLGA
Mount Surface Mount
