LIS3LV02DQ-TR
RoHS
RoHS compliant
RoHS compliantPackage 28-QFN Exposed Pad
Category Sensors, Transducers / Motion Sensors - Accelerometers
Description
ACCEL 2-6G I2C/SPI 28QFPN
PDF
/
Buying Options
Total Price: USD $17.45
Unit Price: USD $17.4515
≥1 USD $17.4515
≥10 USD $14.31935
≥100 USD $13.8719
≥500 USD $13.42445
≥1000 USD $12.977
Inventory: 5202
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Length 7mm
Height Seated (Max) 1.9mm
Technical
Sensitivity (LSB/g) 1024 (±2g) ~ 340 (±6g)
Acceleration Range ±2g, 6g
Axis X, Y, Z
Resolution 2 B
Bandwidth 10Hz ~ 640Hz
Nominal Supply Current 600μA
Interface I2C, SPI
Supply Voltage-Min (Vsup) 2.16V
Power Supplies 1.8/3.32.5V
Supply Voltage-Max (Vsup) 2.64V
Output Type I2C, SPI
Qualification Status Not Qualified
Pin Count 28
Base Part Number LIS3
Terminal Pitch 0.5mm
Supply Voltage 2.4V
Number of Functions 1
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply 2.16V~3.6V
Technology CMOS
Subcategory Other Analog ICs
HTS Code 8542.39.00.01
Type Digital
Number of Terminations 28
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Feature Adjustable Bandwidth, Selectable Scale
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 28
Package / Case 28-QFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
