250A
RoHS
RoHS compliant
RoHS compliantPackage /
Category Industrial Automation and Controls / Monitor - Relay Output
Description
3-PHASE VOLTAGE MONITOR/ 190-4
PDF
/
Buying Options
Total Price: USD $172.02
Unit Price: USD $172.024231
≥1 USD $172.024231
≥10 USD $162.287002
≥100 USD $153.100947
≥500 USD $144.434861
≥1000 USD $136.2593
Inventory: 1614
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Trip Status Energized High/Low
Trip Range 190 ~ 480V AC
Gate-Emitter Thr Voltage-Max 8V
Gate-Emitter Voltage-Max 20V
Collector-Emitter Voltage-Max 2500V
Delay Time Fixed, 4 Sec
Turn Off Time-Nom (toff) 850 ns
Collector Current-Max (IC) 19A
Turn On Time 150 ns
Power Dissipation-Max (Abs) 250W
Contact Rating @ Voltage 10A @ 240VAC
Transistor Application POWER CONTROL
Case Connection ISOLATED
Configuration SINGLE
Circuit DPDT (2 Form C)
Number of Elements 1
Output Type Relay
Qualification Status Not Qualified
JESD-30 Code R-PSIP-T3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form THROUGH-HOLE
Terminal Position SINGLE
Voltage - Supply 190V~480VAC
Subcategory Insulated Gate BIP Transistors
Additional Feature UL RECOGNIZED, HIGH RELIABILITY
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Type Voltage Sensing AC
Number of Terminations 3
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
JESD-609 Code e1
Series 250A
Operating Temperature -40°C~70°C
Physical
Transistor Element Material SILICON
Surface Mount NO
Mounting Type Chassis Mount
Supply Chain
Factory Lead Time 6 Weeks
