84874320
RoHS
RoHS compliant
RoHS compliantPackage /
Category Industrial Automation and Controls / Monitor - Relay Output
Description
RELAY MONITOR SPED 24-240VAC ADJ
PDF
/
Buying Options
Total Price: USD $166.12
Unit Price: USD $166.118214
≥1 USD $166.118214
≥10 USD $156.715294
≥100 USD $147.844622
≥500 USD $139.476057
≥1000 USD $131.58118
Inventory: 1181
Minimum: 1
-
+
Technical Details
Compliance
Ratings IP30
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC Unknown
Dimensions
Width 35mm
Length 65.5mm
Height 90mm
Technical
Coil/Input Supply Type AC/DC
Relay Action LATCHED
Contact/Output Supply Type AC/DC
Coil Power 3000mW
Power Consumption 3W
Release Time 50 ms
Operate Time 50 ms
Contact Current(AC)-Max 5A
Relay Type MONITORING RELAY
Number of Inputs 1
Contact Current Rating 5A
Throw Configuration SPDT
Contact Current(DC)-Max 5A
Operating Supply Voltage 240V
Physical Dimension 90mm x 35mm x 65.5mm
Approval Agency CE, CSA, UL
Number of Outputs 2
Reference Standard CE; CSA; IEC; NF; UL
Power Rating 3W
HTS Code 8536.49.00.50
Min Operating Temperature -20°C
Max Operating Temperature 50°C
ECCN Code EAR99
Termination Terminal Block
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series C-Lynx
Published 2002
Physical
Mount DIN Rail
Supply Chain
Factory Lead Time 4 Weeks
