84873021
RoHS
RoHS compliant
RoHS compliantPackage /
Category Industrial Automation and Controls / Monitor - Relay Output
Description
MWS2 208-480 3PHASE SEQ AND LOSS
PDF
/
Buying Options
Total Price: USD $107.22
Unit Price: USD $107.2192
≥1 USD $107.2192
Inventory: 36
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 17.5mm
Length 65.5mm
Height 92.6mm
Technical
Trip Status Energized High
Trip Range 183 ~ 484V AC
Delay Time No Delay
Coil Voltage (AC) 480V
Contact Rating @ Voltage 5A @ 250VAC
Power Consumption 1.8W
Switching Voltage 250V
Number of Inputs 1
Throw Configuration DPDT
Circuit SPDT (1 Form C) x 2
Operating Supply Voltage 440V
Output Type Relay
Number of Outputs 2
Voltage - Supply 208V~440VAC
Type Phase Loss, Phase Sequence
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series C-Lynx
Published 2006
Operating Temperature -20°C~50°C
Physical
Mounting Type DIN Rail
Mount DIN Rail
Supply Chain
Factory Lead Time 4 Weeks
