2814715
RoHS
RoHS compliant
RoHS compliantPackage /
Category Industrial Automation and Controls / Monitor - Current/Voltage Transducer
Description
DIN Rail Terminal Blocks MCR-S-1/5-UI-DCI-NC
PDF
/
Buying Options
Total Price: USD $435.72
Unit Price: USD $435.7232
≥1 USD $435.7232
Inventory: 70
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 22.86mm
Length 99.06mm
Height 114.3mm
Technical
Input Range 0 ~ 11A
Max Input Current -11A
Min Output Voltage -10V
Response Time 40ms, 330ms
Max Output Voltage 10V
Wire Gauge (Min) 24 AWG
Wire Gauge (Max) 12 AWG
Number of Channels 3
Operating Supply Voltage 30V
Approval Agency CE, UL
Termination Style Screw Terminal
Output ±10VDC, 0 ~ 20mA
Frequency -400Hz
Current Rating 11A
Voltage - Supply 20V~30VDC
Voltage - Rated 30V
Color Green
Type Current Transducer
Connector Type Screw
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series MCR
Published 2003
Operating Temperature -20°C~60°C
Physical
Weight 129.999998g
Number of Pins 16
Mounting Type DIN Rail
Mount DIN Rail, Screw
Supply Chain
Factory Lead Time 7 Weeks
