5-557971-3
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Modular Connectors - Plugs
Description
RoHS Compliant COMMERCIAL UL CSA Cat5 Modular Connector Plug 750Cycles UL94V-2 28AWG 22.24N
PDF
/
Inventory: 5048
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Cat5
Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
Dimensions
Plating Thickness 50μin
Contact Finish Thickness 50.0μin 1.27μm
Length 0.530 13.46mm
Technical
Keyed No
Number of Positions/Contacts 6p6c (RJ11, RJ12, RJ14, RJ25)
Withdrawl Force-Min 22.24 N
Insertion Force-Max 22.24 N
Durability 750 Cycles
Wire Gauge (Min) 26 AWG
Wire Gauge (Max) 28 AWG
Number of Ports 1
Wire/Cable Type Flat
Cable Type Flat Oval Cable, Stranded Wires
ELV Compliant
Insulation Resistance 500000000Ohm
Wire Gauge 26-28 AWG
Contact Resistance 30mOhm
Contact Style TELCOM, MODULAR
Empty Shell NO
Housing Color Blue
UL Flammability Code 94V-0
Body Breadth 0.404 inch
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL, CSA
Number of Positions Loaded 6
Depth 13.47mm
Shielding Unshielded
Orientation Straight
Total Number of Contacts 6
Pitch 1.02mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Telecom and Datacom Connectors
Gender Male
Number of Rows 1
Color Translucent - Blue
Min Operating Temperature -40°C
Max Operating Temperature 60°C
Connector Type Plug
ECCN Code EAR99
Termination IDC
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Published 2005
Packaging Bulk
Physical
Housing Material Polycarbonate (PC)
Mount Cable
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 3 Weeks
