RoHS
RoHS RoHS compliant
Package Metal
Category Connectors, Interconnects / Modular Connectors - Plugs
Description Modular Connectors / Ethernet Connectors VS-PPC-C1-RJ45-MNNA IDC 8P CAT6 MTL HSG
PDF
/
Buying Options
Total Price: USD $23.02
Unit Price: USD $23.0208
≥1 USD $23.0208
≥10 USD $21.1816
≥100 USD $19.569968
≥500 USD $18.649048
≥1000 USD $18.546669
Inventory: 48
Minimum: 1
-
+

Technical Details

Compliance

Ratings Cat6
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant

Dimensions

Length 2.709 68.80mm

Technical

Number of Positions/Contacts 8p8c (RJ45, Ethernet)
Wire Gauge (Min) 24 AWG
Wire Gauge (Max) 26 AWG
Number of Ports 1
Wire/Cable Type Round
Cable Type Round Cable, Solid or Stranded Wires
Max Current Rating 1A
Wire Gauge 24-26 AWG
Empty Shell NO
Number of Contacts 8
Contact Finish Gold
Current Rating 1A
Ingress Protection IP65/67 - Dust Tight, Water Resistant, Waterproof
Shielding Shielded
Orientation Straight
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Voltage - Rated 125V
Gender Male
Color Translucent - Red
Min Operating Temperature -40°C
Max Operating Temperature 70°C
Connector Type Plug
ECCN Code EAR99
Termination IDC
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Cable Clamp, Housing
JESD-609 Code e4
Series PLUSCON VS
Published 2011
Packaging Bulk

Physical

Weight 67.100004g
Housing Material Polycarbonate (PC)
Package / Case Metal
Mount Cable
Contact Material Copper Alloy

Supply Chain

Factory Lead Time 7 Weeks
