0449150002
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Modular Connectors - Plugs
Description
CONN RJ-45 PL 8 POS 1.02MM CRIMP ST CABLE MOUNT 8 TERMINAL 1 PORT BAG CAT 6
PDF
/
Inventory: 6147
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Phosphor Bronze
Mount Cable
Housing Material Polycarbonate (PC)
Technical
Packaging Bulk
Series 44915
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination IDC
Connector Type Plug
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Translucent - Clear
Voltage - Rated 56.5V
Pitch 1.02mm
Orientation Straight
Shielding Unshielded
Depth 22.48mm
Current Rating 1.5A
Contact Finish Gold
Number of Contacts 8
Housing Color Clear
Wire Gauge 22-28 AWG
Cable Type Round Cable, Solid or Stranded Wires
Wire/Cable Type Round
Number of Ports 1
Wire Gauge (Max) 28 AWG
Wire Gauge (Min) 22 AWG
Number of Positions/Contacts 8p8c (RJ45, Ethernet)
Dimensions
Length 0.885 22.48mm
Contact Finish Thickness 50.0μin 1.27μm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Ratings Cat6
