B78477P1007A114

TDK Electronics Inc.
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Modular Connectors - Jacks With Magnetics
Description Down B78477P ROHS3Compliant 2014 Modular Connector (Type) 0C~70C 15.0muin 0.38mum
PDF
/
Inventory: 3271
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Contact Material Phosphor Bronze
Mounting Type Through Hole
Housing Material Thermoplastic
Shield Material Copper Alloy

Technical

Operating Temperature 0°C~70°C
Packaging Tray
Published 2014
Series B78477P
Feature Board Guide
Part Status Obsolete
Moisture Sensitivity Level (MSL) 2 (1 Year)
Termination Solder
Connector Type RJ45
Applications 10/100 Base-T, AutoMDIX
Number of Rows 1
Orientation 90° Angle (Right)
Shielding Shielded, EMI Finger
Contact Finish Gold
Number of Ports 1
LED Color Yellow - Green
Tab Direction Down
Number of Cores per Jack 4

Dimensions

Contact Finish Thickness 15.0μin 0.38μm
Height Above Board 0.541 13.75mm

Compliance

RoHS Status ROHS3 Compliant
