JXR0-0001NL
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Modular Connectors - Jacks With Magnetics
Description
CONN MAGJACK 1PORT 100 BASE-TX
PDF
/
Buying Options
Total Price: USD $8.29
Unit Price: USD $8.2896
≥1 USD $8.2896
≥10 USD $7.4624
≥100 USD $7.02944
≥500 USD $6.849216
≥1000 USD $6.668992
≥3000 USD $5.948061
Inventory: 190
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Material Phosphor Bronze
Mount Through Hole
Mounting Type Through Hole
Housing Material Thermoplastic
Shield Material Brass
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Published 2012
Series PULSEJACK? JXR0
Feature Board Guide
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Connector Type RJ45
Applications 10/100 Base-TX, AutoMDIX
Gender Female
Pitch 2.54mm
Orientation 90° Angle (Right)
Shielding Shielded, EMI Finger
Depth 21.59mm
Contact Finish Gold
Number of Contacts 8
Number of Ports 1
LED Color Does Not Contain LED
Tab Direction Down
Number of Cores per Jack 4
Dimensions
Length 16.26mm
Contact Finish Thickness 30.0μin 0.76μm
Height Above Board 0.545 13.84mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
