JXKM-0004NL
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Modular Connectors - Jacks With Magnetics
Description
CONN MAGJACK 1PORT 1000 BASE-T
PDF
/
Buying Options
Total Price: USD $10.07
Unit Price: USD $10.0672
≥1 USD $10.0672
≥10 USD $8.91968
≥100 USD $8.57648
≥500 USD $8.233667
≥1000 USD $7.776173
≥3000 USD $7.090028
Inventory: 322
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Above Board 0.545 13.84mm
Contact Finish Thickness 15.0μin 0.38μm
Technical
Number of Cores per Jack 8
Tab Direction Down
LED Color Green - Yellow
Number of Ports 1
Contact Finish Gold
Shielding Shielded, EMI Finger
Orientation 90° Angle (Right)
Applications 10/100/1000 Base-T, AutoMDIX
Color Green, Yellow
Connector Type RJ45
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Board Guide
Series PULSEJACK? JXKM
Published 2014
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Shield Material Copper Alloy
Housing Material Thermoplastic
Mounting Type Through Hole
Mount Through Hole
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 11 Weeks
