JXK0-0136NL image
Favorite
JXK0-0136NL image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Modular Connectors - Jacks With Magnetics
Description Conn RJ-45 F 8 POS 2.03mm Solder RA Thru-Hole 16 Terminal 1 Port
PDF
/
Buying Options
Total Price: USD $10.23
Unit Price: USD $10.2344
≥1 USD $10.2344
≥10 USD $9.0684
≥100 USD $8.719392
≥500 USD $8.370754
≥1000 USD $7.90563
≥3000 USD $7.20808
Inventory: 431
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Height Above Board 0.546 13.87mm
Contact Finish Thickness 50.0μin 1.27μm

Technical

Number of Cores per Jack 8
Tab Direction Up
LED Color Yellow, Green - Green
Number of Ports 1
Contact Finish Gold
Shielding Shielded, EMI Finger
Orientation 90° Angle (Right)
Applications 10/100/1000 Base-T, AutoMDIX
Color Green, Yellow
Connector Type RJ45
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Board Guide
Series PULSEJACK? JXK0
Published 2012
Packaging Tray
Operating Temperature -40°C~85°C

Physical

Shield Material Copper Alloy
Housing Material Thermoplastic
Mounting Type Through Hole
Mount Through Hole
Contact Material Phosphor Bronze

Supply Chain

Factory Lead Time 11 Weeks
