JXD0-2019NL image
Favorite
JXD0-2019NL image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Modular Connectors - Jacks With Magnetics
Description CONN MAGJACK 2PORT 1000 BASE-T
PDF
/
Buying Options
Total Price: USD $13.17
Unit Price: USD $13.1736
≥1 USD $13.1736
≥10 USD $11.68024
≥100 USD $11.23115
≥500 USD $10.78191
≥1000 USD $10.182973
≥3000 USD $9.284475
Inventory: 150
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Height Above Board 0.541 13.75mm
Contact Finish Thickness 30.0μin 0.76μm

Technical

Number of Cores per Jack 8
Tab Direction Down
LED Color Green - Yellow
Number of Ports 2
Contact Finish Gold
Shielding Shielded
Orientation 90° Angle (Right)
Number of Rows 1
Applications 10/100/1000 Base-T, AutoMDIX
Connector Type RJ45
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Board Guide
Series PULSEJACK? JXD0
Published 2017
Packaging Tray
Operating Temperature -40°C~85°C

Physical

Shield Material Brass
Housing Material Thermoplastic
Mounting Type Through Hole
Contact Material Phosphor Bronze

Supply Chain

Factory Lead Time 19 Weeks
