JXD0-0012NL
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Modular Connectors - Jacks With Magnetics
Description
Modular Connector Magnetic Jack
PDF
/
Buying Options
Total Price: USD $2.09
Unit Price: USD $2.091732
≥1 USD $2.091732
≥10 USD $2.039406
≥100 USD $2.004086
Inventory: 16
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Above Board 0.537 13.65mm
Contact Finish Thickness 15.0μin 0.38μm
Technical
Number of Cores per Jack 4
Tab Direction Down
LED Color Green - Yellow
Number of Ports 1
Contact Finish Gold
Shielding Shielded, EMI Finger
Orientation 90° Angle (Right)
Applications 10/100 Base-TX
Connector Type RJ45
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Board Lock
Series PULSEJACK? JXD0
Published 2016
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Shield Material Brass
Housing Material Thermoplastic
Mounting Type Through Hole
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 17 Weeks
