JX10-0045NL
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Modular Connectors - Jacks With Magnetics
Description
CONN MAGJACK 1PORT 100 BASE-TX
PDF
/
Inventory: 6083
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Above Board 0.550 13.97mm
Contact Finish Thickness 15.0μin 0.38μm
Technical
Number of Cores per Jack 4
Tab Direction Up
LED Color Green - Green
Number of Ports 1
Contact Finish Gold
Shielding Shielded, EMI Finger
Orientation 90° Angle (Right)
Applications 10/100 Base-TX, AutoMDIX
Connector Type RJ45
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Board Guide
Series PULSEJACK? JX10
Published 2014
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Shield Material Copper Alloy
Housing Material Thermoplastic
Mounting Type Through Hole
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 12 Weeks
