JX0011D21NL image
Favorite
JX0011D21NL image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Modular Connectors - Jacks With Magnetics
Description CONN MAGJACK
PDF
/
Buying Options
Total Price: USD $7.37
Unit Price: USD $7.3656
≥1 USD $7.3656
≥10 USD $6.62816
≥100 USD $6.243776
≥500 USD $6.083616
≥1000 USD $5.923544
≥3000 USD $5.283133
Inventory: 1183
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Height Above Board 0.545 13.84mm
Contact Finish Thickness 15.0μin 0.38μm

Technical

Number of Cores per Jack 4
Tab Direction Down
LED Color Does Not Contain LED
Number of Ports 1
Empty Shell NO
Number of Contacts 8
Contact Finish Gold
Shell Finish NICKEL
Depth 21.59mm
Shielding Shielded, EMI Finger
Orientation 90° Angle (Right)
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature YES
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Gender Female
Applications 10/100 Base-TX, AutoMDIX
Connector Type RJ45
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Board Guide
Series PULSEJACK? JX0
Published 2010
Packaging Bulk
Operating Temperature -40°C~85°C

Physical

Shield Material Brass
Housing Material Thermoplastic
Mounting Type Through Hole
Mount Through Hole
Contact Material Phosphor Bronze

Supply Chain

Factory Lead Time 12 Weeks
