JK0654219NL
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Modular Connectors - Jacks With Magnetics
Description
CONN INTEGRATED MODULE 1PORT
PDF
/
Buying Options
Total Price: USD $16.62
Unit Price: USD $16.6232
≥1 USD $16.6232
≥10 USD $14.41
≥100 USD $13.657952
≥500 USD $13.46004
≥1000 USD $11.876374
≥3000 USD $11.084665
Inventory: 1735
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Height Above Board 0.546 13.87mm
Contact Finish Thickness 30.0μin 0.76μm
Length 18.64mm
Technical
Tab Direction Up
LED Color Green - Green
Insertion Force-Max 22.24 N
Durability 750 Cycles
Number of Ports 1
Body/Shell Style RECEPTACLE
Contact Style TELCOM, MODULAR
Empty Shell NO
UL Flammability Code 94V-0
Body Breadth 0.59 inch
PCB Contact Pattern STAGGERED
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Shell Finish NICKEL
Depth 33.02mm
Shielding Shielded, EMI Finger
Orientation 90° Angle (Right)
Total Number of Contacts 8
Pitch 2.03mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature YES
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Telecom and Datacom Connectors
Additional Feature PULSEJACK, SHIELDED
Gender Female
Applications 10/100/1000 Base-T, AutoMDIX
Number of Positions 8
Connector Type RJ45
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Board Guide
JESD-609 Code e3
Series PULSEJACK? JK0
Published 2009
Packaging Tray
Operating Temperature 0°C~70°C
Physical
Shield Material Copper Alloy
Housing Material Thermoplastic
Mounting Type Through Hole
Mount Through Hole
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 13 Weeks
