JK0-0116NL image
Favorite
JK0-0116NL image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Modular Connectors - Jacks With Magnetics
Description Conn RJ-45 RCP 8 POS Solder RA Thru-Hole 12 Terminal 1 Port
PDF
/
Buying Options
Total Price: USD $10.22
Unit Price: USD $10.2168
≥1 USD $10.2168
≥10 USD $9.19776
≥100 USD $8.664832
≥500 USD $8.442526
≥1000 USD $8.22037
≥3000 USD $7.331738
Inventory: 404
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Height Above Board 0.546 13.87mm
Contact Finish Thickness 30.0μin 0.76μm
Length 18.64mm

Technical

Number of Cores per Jack 8
Tab Direction Up
LED Color Yellow, Green - Green
Direction Up
Number of Ports 1
Number of Contacts 8
Contact Finish Gold
Number of Positions Loaded 8
Depth 33.02mm
Shielding Shielded, EMI Finger
Orientation 90° Angle (Right)
Gender Female
Number of Rows 1
Applications 10/100/1000 Base-T, AutoMDIX
Color Green, Yellow
Min Operating Temperature 0°C
Max Operating Temperature 70°C
Connector Type RJ45
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Board Guide
Series PULSEJACK? JK0
Published 2010
Packaging Tray
Operating Temperature 0°C~70°C

Physical

Shield Material Copper Alloy
Housing Material Thermoplastic
Mounting Type Through Hole
Mount Through Hole
Contact Plating Gold
Contact Material Phosphor Bronze

Supply Chain

Factory Lead Time 11 Weeks
