JC0-0351NL
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Modular Connectors - Jacks With Magnetics
Description
Conn RJ-45 RCP 32 POS Solder RA Thru-Hole 56 Terminal 4 Port
PDF
/
Buying Options
Total Price: USD $26.47
Unit Price: USD $26.4704
≥1 USD $26.4704
≥10 USD $25.19176
Inventory: 1511
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Height Above Board 1.005 25.53mm
Contact Finish Thickness 30.0μin 0.76μm
Technical
Number of Cores per Jack 8
Tab Direction Up and Down
LED Color Green, Yellow - Green, Yellow
Direction Up and Down
Number of Ports 4
Empty Shell NO
Number of Contacts 32
Contact Finish Gold
Shell Finish NICKEL
Shielding Shielded, EMI Finger
Orientation 90° Angle (Right)
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature YES
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Gender Female
Number of Rows 2
Applications 10/100/1000 Base-T, AutoMDIX
Color Green, Yellow
Connector Type RJ45
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Board Guide
JESD-609 Code e3
Series PULSEJACK? JC0
Published 2010
Packaging Tray
Operating Temperature 0°C~70°C
Physical
Shield Material Copper Alloy
Housing Material Thermoplastic
Mounting Type Through Hole
Mount Through Hole
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 11 Weeks
