JC0-0132NL
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Modular Connectors - Jacks With Magnetics
Description
CONN MAGJACK 12PORT 1000 BASE-T
PDF
/
Inventory: 1236
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Height Above Board 1.005 25.53mm
Contact Finish Thickness 30.0μin 0.76μm
Length 89mm
Technical
Number of Cores per Jack 8
Tab Direction Up and Down
LED Color Does Not Contain LED
Direction Up and Down
Number of Ports 12
Empty Shell NO
UL Flammability Code 94V-0
Number of Contacts 96
Contact Finish Gold
Shell Finish NICKEL
Depth 28.95mm
Shielding Shielded, EMI Finger
Orientation 90° Angle (Right)
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature YES
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Gender Female
Number of Rows 2
Applications 10/100/1000 Base-T, AutoMDIX
Connector Type RJ45
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Board Guide
JESD-609 Code e3
Series PULSEJACK? JC0
Published 2009
Packaging Bulk
Operating Temperature 0°C~70°C
Physical
Shield Material Brass
Housing Material Thermoplastic
Mounting Type Through Hole
Mount Through Hole
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 11 Weeks
