J8064E66NL image
Favorite
J8064E66NL image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Modular Connectors - Jacks With Magnetics
Description CONN MAGJACK 6PORT 100 BASE-TX
PDF
/
Inventory: 4655
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 11 Weeks

Physical

Contact Material Phosphor Bronze
Mount Through Hole
Mounting Type Through Hole
Housing Material Thermoplastic
Shield Material Brass

Technical

Operating Temperature 0°C~70°C
Packaging Tray
Published 2009
Series PULSEJACK? J8
Feature Board Guide
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Connector Type RJ45
Applications 10/100 Base-TX, AutoMDIX
Number of Rows 1
Pitch 2.54mm
Orientation 90° Angle (Right)
Shielding Shielded, EMI Finger
Contact Finish Gold
Number of Contacts 48
Number of Ports 6
LED Color Does Not Contain LED
Tab Direction Down
Number of Cores per Jack 4

Dimensions

Contact Finish Thickness 30.0μin 0.76μm
Height Above Board 0.536 13.61mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
