J3011G21D image
Favorite
J3011G21D image
Favorite
RoHS
/
Package /
Category Connectors, Interconnects / Modular Connectors - Jacks With Magnetics
Description Conn RJ-45 F 8 POS 1.02mm Solder RA SMD 12 Terminal 1 Port Tray
PDF
/
Buying Options
Total Price: USD $2.81
Unit Price: USD $2.80725
≥1 USD $2.80725
≥10 USD $2.3028
≥100 USD $2.23155
≥500 USD $2.15935
≥1000 USD $2.08715
Inventory: 10608
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Radiation Hardening No

Dimensions

Height Above Board 0.536 13.61mm
Contact Finish Thickness 15.0μin 0.38μm
Length 16.1mm

Technical

Number of Cores per Jack 4
Tab Direction Up
LED Color Green - Yellow
Number of Ports 1
Empty Shell NO
Contact Finish Gold
Shell Finish NICKEL
Depth 25.4mm
Shielding Shielded
Orientation 90° Angle (Right)
Total Number of Contacts 8
Pitch 1.02mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature YES
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Voltage - Rated DC 1.5kV
Voltage - Rated 1.5kV
Gender Female
Applications 10/100 Base-TX, AutoMDIX
Color Black
Number of Positions 8
Connector Type RJ45
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Feature Board Guide
Series PULSEJACK? J3
Published 2008
Packaging Tray
Operating Temperature 0°C~70°C

Physical

Shield Material Brass
Housing Material Thermoplastic
Mounting Type Surface Mount
Mount Surface Mount
Contact Material Phosphor Bronze
