J2042H3C
RoHS
/
Package /
Category Connectors, Interconnects / Modular Connectors - Jacks With Magnetics
Description
Modular Connector Magnetic Jack
PDF
/
Inventory: 8532
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Phosphor Bronze
Mount Through Hole
Mounting Type Through Hole
Housing Material Thermoplastic
Shield Material Brass
Technical
Operating Temperature 0°C~70°C
Packaging Bulk
Published 2003
Series PULSEJACK? J2
Feature Board Guide
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Connector Type RJ45
Number of Positions 8
Color Black
Applications 10/100 Base-TX, AutoMDIX
Number of Rows 2
Gender Female
Voltage - Rated DC 1.5kV
Pitch 2.54mm
Orientation 90° Angle (Right)
Shielding Shielded, EMI Finger
Contact Finish Gold
Number of Contacts 128
Number of Ports 16
Direction Up and Down
LED Color Does Not Contain LED
Tab Direction Up and Down
Number of Cores per Jack 4
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Height Above Board 1.005 25.53mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
